kameljoe21 1971 Eagle 05

This is a public forum. This forum will be a place to show your Project Eagle and updates on progress you have made. Please make one thread with your project and put all updates in the same thread. Sorry... Eagles only.
Re: kameljoe21 1971 Eagle 05
Wed Nov 06, 2013 8:11 pm


bus heat
after thought
this heater sucks and its still in but we installed
a glo warm and heats much better



electral panel
to make a long story short
test the outlet you intend to plug in to to make sure the hot and common
are not crossed
i lost my automatic transfer switch do to this mistake
i dont care if it your own house all ways check to make sure
120 volt plug in tester to see what its at
free from friend

50 amp auto breaker

i opend up the unit to see how it was wired and seen that i can snip the 6 fuse
panel and wire it in to what ever i want so i made the above panel from old stock
stuff at napa for less than 50 bucks
i made it so that i never have to disconect from the fuse block itself just the other thing





gen set Gas
sat for 10 plus years since used and fired up first try after i primed it
runs great
have put a large load on it yet but put a test load on it






Joe Glaser
Joes, Colorado
1971 Silver Eagle
Series 05
Vin 8446
http://s853.photobucket.com/user/kamelj ... er%20Eagle
kameljoe21

Posts: 46
Joined: Sat Jun 15, 2013 11:12 pm
Location: Joes, Colorado Living in the bus since Sept 24 2013


Re: kameljoe21 1971 Eagle 05
Wed Nov 06, 2013 8:38 pm


driver seat wall
with ply wood recessed in to allow adding tv on it with out it fallling out



we have been lo\iving in the bus up to this point for about a month

rare find an uppper lazy suzan cabinet
metal is lighter than wood and i like the look for now



re did desk area in to this
being used as food pantry
what we were going to when it was the other way
but this way is better and adds some more room to the back bunk



my bunk



shelf i made for my bunk





thats the last photo for now
well not true im up loading a few i have missed

so ill tell you some other things i have rounded up

one is i found some waste tanks about 100 gallons each still have to do figuars
but they were only 30 buck for both and are older fertilizer tanks and should work

i also got a propane tank 107 gallons off of a combine for helping cut and split wood
for a friend for 2 half days
alos for those who want to know propane is 4.11 pounds per gallon

i got my norcold fridege in the bus still havent done the vent just on elect for now

glo warm heater installed
it makes it hot in here
has any one ever set up a real wall thermastat with it
if so that would be nice

i have got a bunch of water tanks
and other whats nots for it still working on where i want to place them

i got a free concreat shower base that will work just right

ok this is what was there and now is not
when i hooked up elect via this plug i shorted out and thought that there was a mis wireing
turns out it was the main sorce being crossed hot and common
i should have checked that before i plug in



auto matic transefer switch broken due to bad wireing


pass seat



heater vents, will become AC

Joe Glaser
Joes, Colorado
1971 Silver Eagle
Series 05
Vin 8446
http://s853.photobucket.com/user/kamelj ... er%20Eagle
kameljoe21

Posts: 46
Joined: Sat Jun 15, 2013 11:12 pm
Location: Joes, Colorado Living in the bus since Sept 24 2013


Re: kameljoe21 1971 Eagle 05
Wed Nov 06, 2013 8:47 pm


Well i wanted photos of the tire comparment

so i took some








ok that was the last one
will do some more current one soon

the other thing i got was some more metal cabinet that i have painted sanded and wire brushed , i for got to take pic of the before
Joe Glaser
Joes, Colorado
1971 Silver Eagle
Series 05
Vin 8446
http://s853.photobucket.com/user/kamelj ... er%20Eagle
kameljoe21

Posts: 46
Joined: Sat Jun 15, 2013 11:12 pm
Location: Joes, Colorado Living in the bus since Sept 24 2013


Re: kameljoe21 1971 Eagle 05
Wed Nov 06, 2013 9:03 pm


Tags for bus were 206 dollars
should be 175 a year

insureance for one year full covarge for 15,000
with 100 deductable for glass and free repairs
1000 damage deductable
all for 147 dollars a year

got them done the other day so i thought i would add that
Joe Glaser
Joes, Colorado
1971 Silver Eagle
Series 05
Vin 8446
http://s853.photobucket.com/user/kamelj ... er%20Eagle
kameljoe21

Posts: 46
Joined: Sat Jun 15, 2013 11:12 pm
Location: Joes, Colorado Living in the bus since Sept 24 2013


Re: kameljoe21 1971 Eagle 05
Wed Nov 06, 2013 9:05 pm


Wow Joe, you are really making headway!!!

What was the insulation you used. I saw the box, but it did not give me much information.

Jim
Jim Shepherd
Evergreen, CO
'85 Eagle 10 with Series 60 & Eaton AutoShift 10 speed transmission - not at all fancy, but fully functional
Bus Project pages: http://beltguy.com/Bus_Project/busproject.htm
Blog: http://beltguy.com/blog/
Email: jim@eaglesinternational.net (Please email me rather than use the PM process)
User avatar
beltguy
Moderator
Moderator

Posts: 2058
Joined: Wed Oct 08, 2008 4:39 am
Location: Evergreen, CO


Re: kameljoe21 1971 Eagle 05
Wed Nov 06, 2013 10:07 pm


Looks pretty good!
Joe Laird
'78 05
Sioux Falls, SD
User avatar
akroyaleagle
Club Member
Club Member

Posts: 460
Joined: Tue Oct 14, 2008 12:11 pm
Location: Sioux Falls, SD


Re: kameljoe21 1971 Eagle 05
Thu Nov 07, 2013 10:40 am


its a radiant barrier foil

In quick this is what it does

as heat touches the out side of the bus and radiants
thru the shell and begins to heat up the bus making
it hot as hell

with the radiant barrier i create a dead air space of
2 inches plus which allows the heat to bounce back
they way it came

allowing the bus to stay cooler

this works both ways for heat and cold

so far its working in the cold and will work even more
when i finsih the ceiling, i have to wait till i finsh running
wiring thru out

http://www.atticfoil.com/
I order a 1000 square feet for 150 with the shiping

after thought, I should have put in all new floor
so that i could have put the barrier under the floor
but at the time i didnt see spending 500 or more
to get the plywood as most of the floor was in pretty good shape
Joe Glaser
Joes, Colorado
1971 Silver Eagle
Series 05
Vin 8446
http://s853.photobucket.com/user/kamelj ... er%20Eagle
kameljoe21

Posts: 46
Joined: Sat Jun 15, 2013 11:12 pm
Location: Joes, Colorado Living in the bus since Sept 24 2013
